What to Know About Bathroom Exhaust Fan Installation in Pasadena, MD

Bathroom exhaust fans come in all shapes and sizes in order to accommodate small or large bathrooms, so you are able to choose from a variety of options for your bathroom vent installation. While exhaust fans typically range from 50 CFM to 150 CFM or larger for huge bathrooms, most typical houses need 50-80 CFM for a half bath and 80 to 150 CFM for a full bath.  If you're modifying an older home, building a new bathroom, or building a new home - a qualified electrician can help you make the right choice for your situation!

When it comes to bathroom fan replacement & installation, the list of options is rather extensive, as you can choose from a diverse list of customizable additions such as:

• Bath fan lights and heaters.
• Bluetooth exhaust fans that sync with your phone, so you can add a soundtrack to your relaxing bath.
• Motion-sensing exhaust fans are great for guests and powder rooms.
• Humidity sensing exhaust fans are amazing for any bathroom where steam is an issue.
• Control your fan your way with a switch, timer, motion sensor or humidity level detection.

CFM And Decibels

The size of a bathroom exhaust fan is based on the size of the room.  Our experienced professional will measure the room and plan accordingly.  For example, if the room is 60 cubic feet (width X length X depth), you will need a fan marked for at least 70 CFM . Many of the fans on the market today move 100 CFM or more.  That can clear out the bathroom in a hurry.  Although you don’t want the fan to sound like a revving jet engine, the decibel level is not super important.  That being said however, you do want it to be loud enough to muffle bathroom noises and loud enough that you can hear it running long after you would have forgotten about it.

Proper equipment for Installing a new bathroom fan includes flexible tubing to direct the air and moisture outside the house. If the technician is using existing tubing, he might have to make some adjustments in case the tubing is larger than the opening in the fan’s exhaust.  If that is the case, our certified electrician can tighten the tubing around the fan exhaust with zip strips then run duct tape around the tubing to secure it to the fan and ensure as little loss of air as possible.

How Our Experts Install Your Bathroom Exhaust Fan near Pasadena, MD

• If the system is new, our electrician will need to make a hole in the wall of the house that is slightly larger than the tubing.  Usually, our technician will then attach the tubing to a louver or flap on the outside of the house. The flap will be opened by the air being pushed out by the fan. The flap should snap snugly shut once the fan stops. The opening must close quickly to prevent squirrels and other wild animals from getting into the tube. These critters look cute in cartoons but are unwelcome house guests.
• With the air duct and exit flap taken care of, the technician can focus on the bathroom exhaust fan itself.  Often the new fan is larger and more powerful than the one being replaced.  This means a bigger hole is needed in the ceiling. The technician will hold the metal frame for the fan up to the ceiling and draw around it with a pencil. Before cutting a larger hole in the ceiling with a drywall knife or box cutter, he must remove the old fan being careful to unplug the device first.
• Wires will now be dangling down through the hole just created.  The electrician will thread the wires through a fairly large hole in the fan frame specifically for this purpose. Often the technician will slip the wires through a rubber grommet into the hole in the frame.  This will prevent the wires from scraping against the edges of the metal hole because of the vibration from the fan when it is running.
• The electrician now is ready to secure the assembly to the studs in the ceiling. Since a bathroom exhaust fan is relatively light, four wood screws are usually plenty for the job.
• Next, the technician twists the dangling power wires to the wires from the fan – white wires twisted together, black wires twisted together, and the ground wire attached to a grounded position.  The wires are secured with plastic wire caps.
• The electrician pushes the fan into the metal frame and secures it with screws or with pre-manufactured clips. The plastic screen is pushed into place over the fan and fits flush with the ceiling.
• Now it’s time for a final test on the wiring for the new bathroom fan. I good way to test this is to hold a piece of paper close to the fan.  When you flip the switch, the fan should create enough suction that it pulls the paper upward and holds it against the screen.
• Job well done.  Not quite.  What about the wall switch? If there was previously a fan, then our electrician will inspect the switch and wires and make sure all is well. But if you are installing a fan where there wasn't one we will have to run the wire to the switch.
• Finally, our electrician will test the whole system. He will turn the switch on, let the fan run for a while, then turn it off.  He will repeat this a couple of times. If we have installed a timer, he will set the timer and come back at an appropriate time to see if the fan had switched off as it should.
• Now you can have a bathroom free of moisture and smells in short order. Your installation of a new bathroom exhaust fan is complete.
